本篇文章主要讲述【云计算】解析Traefik HTTPS 配置，希望阅读本篇文章以后大家有所收获，帮助大家对相关内容的理解更加深入。

1.Traefik

1.1 TLS

# 针对 "traefik"，"cert" 名字必须是 "tls.crt"， "key" 名字必须是 "tls.key"，"traefik-ingress-controller-xxxxx" pod 默认读取对应名字 # "-subj" 是可选项
mkdir -p ~/addon/traefik/pki
cd ~/addon/traefik/pki
openssl req -x509 -nodes -days 3650 -newkey rsa:2048 -keyout tls.key -out tls.crt -subj "/CN=netonline.com"
# "traefik" 应用默认部署在 "kube-system" ，在对应 "namespace" 创建 "secret" 资源
kubectl create secret generic traefik-cert --from-file=/root/addon/traefik/pki/tls.crt --from-file=/root/addon/traefik/pki/tls.key -n kube-system

1.2 ConfigMap

# 以下配置适用于全部采用 "https" 的场景，"http" 访问会被重定向为 "https" # "traefik.toml" 需要与 "traefik-ingress-controller-xxxxx" pod 中的启动参数的文件名一致# "insecureSkipVerify = true" ，此配置指定了 "traefik" 在访问 "https" 后端时可以忽略TLS证书验证错误，从而使得 "https" 的后端，可以像http后端一样直接通过 "traefik" 透出，如kubernetes dashboard# "insecureSkipVerify = true" 变更配置需要重启 pod 才会生效
cat ~/addon/traefik/traefik.toml
insecureSkipVerify = true
defaultEntryPoints = ["http","https"]
[entryPoints]
  [entryPoints.http]
  address = ":80"
    [entryPoints.http.redirect]
    entryPoint = "https"
  [entryPoints.https]
  address = ":443"
    [entryPoints.https.tls]
      [[entryPoints.https.tls.certificates]]
      # 默认路径，勿修改
      certFile = "/ssl/tls.crt"
      keyFile = "/ssl/tls.key"
# 生成 "configmap" 资源
kubectl create configmap traefik-conf --from-file=/root/addon/traefik/traefik.toml -n kube-system

1.3 编辑 traefik-ds.yaml

# 挂载 "secret" 与 "configmap" 资源# 添加 "https" 服务端口# 添加 "traefik-ingress-controller-xxxxx" pod 启动参数cat ~/addon/traefik/traefik-ds.yaml ---apiVersion: v1kind: ServiceAccountmetadata:  name: traefik-ingress-controller  namespace: kube-system---kind: DaemonSetapiVersion: extensions/v1beta1metadata:  name: traefik-ingress-controller  namespace: kube-system  labels:    k8s-app: traefik-ingress-lbspec:  template:    metadata:      labels:        k8s-app: traefik-ingress-lb        name: traefik-ingress-lb    spec:      serviceAccountName: traefik-ingress-controller      terminationGracePeriodSeconds: 60

      # 挂载 "secret" 与 "configmap" 资源      volumes:      - name: ssl        secret:          secretName: traefik-cert      - name: config        configMap:          name: traefik-conf      containers:      - image: traefik:v1.7.12        name: traefik-ingress-lb

        # 设置挂载点        volumeMounts:        - mountPath: "/ssl"          name: "ssl"        - mountPath: "/config"          name: "config"        ports:        - name: http          containerPort: 80          hostPort: 80

        # 添加应用端口        - name: https          containerPort: 443          hostPort: 443        - name: admin          containerPort: 8080          hostPort: 8080        securityContext:          capabilities:            drop:            - ALL            add:            - NET_BIND_SERVICE        args:

        # 添加启动参数 "--configfile=/config/traefik.toml"，注意路径与文件名与 "configmap" 的对应        - --configfile=/config/traefik.toml        - --api        - --kubernetes        - --logLevel=INFO---kind: ServiceapiVersion: v1metadata:  name: traefik-ingress-service  namespace: kube-systemspec:  selector:    k8s-app: traefik-ingress-lb  ports:    - protocol: TCP      port: 80      name: web

    # 添加服务端口    - protocol: TCP      port: 443      name: https    - protocol: TCP      port: 8080      name: admin

# 生成 "traefik" 应用kubectl apply -f /root/addon/traefik/traefik-ds.yaml

2. Ingress

2.1 Ingress without TLS

# 针对已经设置完全重定向的 "traefik" ，"ingress" 资源可直接不带 "tls" 属性cat ~/addon/traefik/ui.yamlapiVersion: extensions/v1beta1kind: Ingressmetadata:  name: traefik-web-ui  namespace: kube-systemspec:  rules:  - host: traefik.netonline.com    http:      paths:      - path: /        backend:          serviceName: traefik-web-ui          servicePort: web

2.2 Ingress with TLS

# 如果需要代理的应用不在 "kube-system" ，需要在对应 "namespace" 创建对应的 "secret"，方便 "tls:secretName" 属性调用读取kubectl create secret generic traefik-cert --from-file=/root/addon/traefik/pki/tls.crt --from-file=/root/addon/traefik/pki/tls.key -n default

# 附带 "tls:secretName" 属性的 "ingress" 资源示例cat ~/addon/traefik/ui.yamlapiVersion: extensions/v1beta1kind: Ingressmetadata:  name: traefik-web-ui  namespace: kube-system  annotations:

    kubernetes.io/ingress.class: traefikspec:  tls:  - secretName: traefik-cert  rules:  - host: traefik.netonline.com    http:      paths:      - backend:          serviceName: traefik-web-ui          servicePort: 80
